Technology

LoRaWAN®, Milesight D2D

Antenna

Internal Antenna or External Antenna (Hardware Optional)
External Antenna (EA) Version: 1 × 50 Ω SMA Female Connector

Frequency

IN865

Tx Power

16dBm (868 MHz)/20dBm (915 MHz)/19dBm (470 MHz)

Sensitivity

-137dBm @300bps

Working Mode

OTAA/ABP Class A, Class B, Class C, Class C to B

Interface Type

M12 A-Coded Male

Solenoid Interface

Ports

2 × Solenoid Interfaces

Solenoid Support

2 Wires DC 12V Latching Solenoids

Cable Length

1.5m (by Default)

GPIO Interface

Ports

2 × Digital Inputs, Dry Contact

Work Mode

Digital Input, Pulse Counter

Operation

Power On & Off

Mobile App (via NFC), PC Software (via USB Type-C), Power Button (Internal), Cable Connection

Configuration

Mobile App(via NFC) or PC Software (via USB Type-C)

Advanced Feature

Multicast, Data Storage, Data Retransmission, Data Retrievability, Milesight D2D Agent, Local Rules

Power Connector

M12 A-Coded Male (EA Version Only)

Power Supply

1.Solar Powered (6V, 1.7W)
2.2 × 2550 mAh Chargeable Batteries
3.5-24 VDC (EA Version Only)

Battery Life*(20 min interval + control valve 4 times per day, 25°C)

When battery level is full and does not charge:
Class A: Around 3 years
Class B: Around 350 days
Class C: Around 25 days

Operating Temperature

-20°C~60°C

Ingress Protection

IP68 (1m underwater, 7 days)

Dimension

116 × 116 × 45.5 mm (4.56 × 4.56 × 1.79 in) (Connectors Excluded)

Weight

IA Version: 425g EA Version: 467g

Installation

Wall or Pole Mounting

Regulatory

CE, FCC

Environmental

RoHS
