Technology

LoRaWAN®

Frequency

CN470/IN865/RU864/EU868/US915/AU915/KR920/AS923

Tx Power

16dBm(868)/20dBm(915)/19dBm(470)

Sensitivity

-137dBm @300bps

Mode

OTAA/ABP Class A

Range

0 - 100000 lux

Accuracy

±3%

Resolution

1 lux

Power On & Off

NFC, Power Button (Internal)

Configuration

Mobile APP(via NFC) or PC software(via USB Type-C)

Cable Length

3 m

Power Supply

19000 mAh Li-SOCL2 battery (ER34615)

Battery Life*

10 years (10 min interval)

Operating Temperature

-30°C to +60°C

Relative Humidity

0% to 100% (non-condensing)

Ingress Protection

IP67(Transceiver)/IP65(Light Sensor)

Dimension

Transceiver: 105.4 × 71 × 69.5 mm (4.1 × 2.8 × 2.7 in)
Light Sensor: 64 × 58 × 34 mm (2.5 × 2.3 × 1.3 in)

Installation

Pole, wall or DIN Rail Mounting

Regulatory

CE, FCC, RoHS
