Membrane Leakage Detection Sensor

EM300-MLD

₹15277.50₹13095.00

Wireless Transmission

Technology

LoRaWAN®, Milesight D2D

Frequency

CN470/IN865/RU864/EU868/US915/AU915/KR920/AS923-1&2&3&4

Tx Power

16dBm(868 MHz)/20dBm(915 MHz)/19dBm(470 MHz)

Sensitivity

-137dBm @300bps

Mode

OTAA/ABP Class A

Leakage Detection

Liquid Type

Conductive Liquid

Trigger Media

400 × 400 × 0.25 mm Printed Leakage-Detecting Film
(The size can be customizable)

Trigger Condition

When the Sensing Film Contact Conductive Liquid

Operation

Power On & Off

NFC, Power Button (Internal)

Configuration

NFC Configuration via Mobile App

Advanced Feature

Milesight D2D Controller, Data Storage, Data Retransmission

Physical Characteristics

Cable Length

1000 mm (Customizable)

Power Supply

1 × 4000 mAh ER18505 Li-SOCL2 Battery (Extendable to 2 Batteries)

Battery Life*

Up to 10 Years (One hour Leakage per Day, 25°C)

Operating Temperature

-30°C~70°C

Relative Humidity

0% to 95% (non-condensing)

Color & Material

White Flame, ABS + PC (Retardant)

Ingress Protection

IP67

Dimension

105.6 × 85.3 × 27 mm (4.16 × 3.36 × 1.06 in)

Installation

Wall Screw Mounting, 3M Tape Mounting, Cable-Tie Mounting
