Protocol

LoRaWAN®

Frequency

CN470/IN865/RU864/EU868/US915/AU915/KR920/AS923-1&2&3&4

Tx Power

16 dBm (868 MHz)/22 dBm (915 MHz)/19 dBm (470 MHz)

Sensitivity

-132dBm@300bps

Mode

OTAA/ABP Class A

ToF FoV

25 °

FoV Accuracy

± 5 °

Detection Range

1 ~ 55 cm

Detection Accuracy

± 1cm

Detection Resolution

①1mm (1.0≤X≤15.0cm)
②2mm (15.0＜X≤35.0cm)
③3mm (35.0＜X≤55.0cm)
X = Detection Distance

Button

1 × Reset Button (Internal)

LED Indicator

1 × Indicator (Internal)

Configuration

Mobile App (via NFC)

Power Supply

1 × 590mAh CR2450 Lithium Battery

Battery Life1

2 Years

Operating Temperature

-10°C ~ +60°C

Relative Humidity

0 ~ 95% (Non-condensing)

Color & Material

White, ABS + PC (Flame Retardant)

Ingress Protection

IP30

Dimension

66 × 38 × 12 mm (2.60 × 1.50 × 0.47 in)

Installation

On the flat surfaces with 3M tapes

Warranty2

2 Years
